# Analyze Complex Roots Tool

Type

Requires

Implementation Type

Programming Language

is compatible with

Supported image dimension

Interaction Level

License/Openness

License

MIT

Description

This tool allows to analyze morphological characteristics of complex roots. While for young roots the root system architecture can be analyzed automatically, this is often not possible for more developed roots. The tool is inspired by the Sholl analysis used in neuronal studies. The tool creates a binary mask and the Euclidean Distance Transform from the input image. It then allows to draw concentric circles around a base point and to extract measures on or within the circles. Instead of circles, which present the distance from the base point, horizontal lines can be used, which present the distance in the soil from the base-line. The following features are currently implemented:

- The area of the root per distance/depth.
- The number of border pixel per distance/depth, giving an idea of the surface in contact with the soil.
- The maximum radius per distance/depth of a root, measured at the crossing points with the circles or lines.
- The number of crossings of roots with the circles or lines.
- The maximum distance to the left and the right from the vertical axis at crossing points with the circles or lines.

has function

has biological terms

Entry Curator
